STORE, WORKSHOP, AND FACILITY

Piping Workshop
CNC Machine Workshop
Warehouse
Storage
  • CNC No 1, 2, 3 (Plasma Cutting Machine) Capacity Up to 3600 tons/month
  • QCLY - 500 ton Single arm hydraulic press body machine
  • Hydraulic Press 1000 Tons
  • QCWL-240 ton frame bender machine
  • Frame Bending and Straightening Machine 450 Tons
  • Hydraulic Press Brake c/w 80 4000 x 400 tons capacity
  • Three Roll Bending Machine 30mm x 1500
  • Shearing Cutting Machine max 25 Thickness
  • High pressure air compressor for CNC usage
  • Semi automatic Pipe cutting machine
  • Pump tester
  • Bench Drill Machine
  • Hydraulic Pipe Bender
  • Chop Saw
  • Hydraulic Cutter

BLASTING SHOP

  • Mobile Blasting Recycle (MBR)
  • Dehumidifier 12.000 Btu
  • Vacuum Recovery System 90 Kw
  • Vacuum Pot
  • Sucking Vacuum
  • Blast Pot / Hopper
  • Air Cooler
  • Airless Spray Pump
  • Mini Sandpot 200 lbs
  • Conventional Airspray
  • Mixer

MACHINERY EQUIPMENT

Auto Radial Drilling Machine
Shapping Machine
Lathe Machine
Bed Lathe Machine
Drilling & Milling Machine
Pipe Bending Machine
  • Lathe Machine S480 X 1000
  • Lathe Machine CA-6266C/2000
  • Lathe Machine 10,000mm x 830mm diameter
  • 650 mm Shapping Machine / AK-464 Type STC 26
  • Auto Radial Drilling Machine Type STC 50160
  • Drilling & Milling Machine / Gear Type CZ-45G
  • Pipe Bending Machine Max dia 100A

SUPPORTING EQUIPMENT

Generator
Air Compressor
Welding Set
  • Generator 30 Unit, Total 12,000 KVA
  • Air Compressor
  • SAW (Auto Weld)
  • FCAW (Mig)
  • SMAW
  • GTAW
  • Auto Cutting Mach

TRANSPORT & LIFTING

Transporter
Gantry Crane
Crawler Crane
Forklift
Tug Boat and Tongkang
Trado
Trailer 100T
Cherry Picker
  • Transporter
  • Crawler Crane
  • Gantry Crane
  • Mobile Crane
  • Trailer
  • Forklift
  • Cherry picker
  • Tugboat & Barge
  • Maximum 200 tons lifting
  • Maximum 250 T
  • Up to 40T
  • Up to 25T
  • Up to 100T
  • Up to 10T
  • 3 people
  • Capacity Up to 5,000 Ton

ASSEMBLY & ERECTION AREA

  • Assembly 1
  • Assembly 2
  • Assembly 3
  • Assembly 4
  • Assembly 5
  • Assembly 6
  • Assembly 7
  • 30 x 160 meter
    - Concrete beam + Gantry Crane 20T
  • 30 x 160 meter
    - Concrete beam + Gantry Crane 20T
  • 30 x 160 meter
    - Concrete beam + Gantry Crane 20T
  • 30 x 160 meter
    - Concrete beam + Gantry Crane 20T
  • 30 x 160 meter
    - Concrete beam + Gantry Crane 20T
  • 30 x 160 meter
  • 130 x 350 meter

FLOATING DOCK

  • 12,000 TLC floating dock to serve vessels with capacity up to 50,000 DWT
  • LOA: 188 x 49 x 16 meter
  • Draft: 2.7 meter
  • Work space: 176 x 40 meter

LAUNCHING YARD

  • Launching yard has capacity to accommodate vessels with capacity up to 50,000 DWT
  • Dimension: 216 x 65 meter
  • Sloping profile: 1.5 degree

OFFICE

Main Office
Site Office
Yard Office
